How to Install Jenkins on Windows, Ubuntu and CentOS?

jenkins
Invicti Web Application Security Scanner – the only solution that delivers automatic verification of vulnerabilities with Proof-Based Scanning™.

A step-by-step Jenkins installation guide.

In this article, we will learn how to install Jenkins on the following operating systems.

  • Windows
  • CentOS
  • Ubuntu

For all the above operating systems, Jenkins installation steps slightly vary, but configuration steps are the same.

What is Jenkins?

Jenkins is an open-source automation building tool for developers to run around projects and applications. It is used for building and deploying software and application. It is a powerful automation application that allows constant integration and continuous delivery of projects, regardless of the platform you are working on.

Since Jenkins is a Java application, it runs standalone by any machine with a Java Runtime Environment (JRE) installed.

If you are looking to learn Jenkins then check out this online course to become a hero from zero.

Prerequisite

JDK8+ is mandatory for all operating systems. So first we need to install JDK8 or higher version. You can download and install it from here.

Jenkins Installation on Windows

Once JDK is installed and running, we are ready to download and install Jenkins. Click here to download the latest Jenkins MSI package for Windows.

  • Double click on jenkins.msi to begin the installation.
  • Click on Next and then install
  • Click on the Change button if you want to install it in another directory. In this example, we will keep the default option, click Next
  • When done with the installation process, click the Finish button to complete the installation.

As you can see the Jenkins installation in Windows is really easy. Just like any other standard software.

Jenkins Installation on Ubuntu

As mentioned earlier, make sure JDK8+ is installed and running on the Ubuntu machine. If it is not installed execute below command to install it.

sudo apt install default-jdk-headless

geekflare@ubuntu:~$ sudo apt install default-jdk-headless
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following NEW packages will be installed:
  default-jdk-headless
0 upgraded, 1 newly installed, 0 to remove and 102 not upgraded.
Need to get 1132 B of archives.
After this operation, 6144 B of additional disk space will be used.
Get:1 http://archive.ubuntu.com/ubuntu bionic-updates/main amd64 default-jdk-headless amd64 2:1.11-68ubuntu1~18.04.1 [1132 B]
Fetched 1132 B in 2s (676 B/s)
Selecting previously unselected package default-jdk-headless.
(Reading database ... 30061 files and directories currently installed.)
Preparing to unpack .../default-jdk-headless_2%3a1.11-68ubuntu1~18.04.1_amd64.deb ...
Unpacking default-jdk-headless (2:1.11-68ubuntu1~18.04.1) ...
Setting up default-jdk-headless (2:1.11-68ubuntu1~18.04.1) ...
geekflare@ubuntu:~$

To verify Java has been installed successfully, execute the below command:

java -version

geekflare@ubuntu:~$ java -version
openjdk version "11.0.7" 2020-04-14
OpenJDK Runtime Environment (build 11.0.7+10-post-Ubuntu-2ubuntu218.04)
OpenJDK 64-Bit Server VM (build 11.0.7+10-post-Ubuntu-2ubuntu218.04, mixed mode, sharing)
geekflare@ubuntu:~$

Once it is installed, then we are good to go for Jenkins installation.

Installation Steps:

Step 1 : First, Open command terminal (Ctrl + Alt + T)

Step 2: For installing Jenkins, Let’s adding repository key to the system

<span style="font-weight: 400;">wget -q -O - http://pkg.jenkins-ci.org/debian/jenkins-ci.org.key | sudo apt-key add -</span>

geekflare@ubuntu:~$ wget -q -O - http://pkg.jenkins-ci.org/debian/jenkins-ci.org.key | sudo apt-key add -
OK
geekflare@ubuntu:~$

Step 3: Once the key is added, we need to append the Debian package repos address to the machine.

<span style="font-weight: 400;">sudo sh -c 'echo deb http://pkg.jenkins-ci.org/debian-stable binary/ > /etc/apt/sources.list.d/jenkins.list'</span>

Step 4: Now update Ubuntu packages

<span style="font-weight: 400;">sudo apt update</span>

geekflare@ubuntu:~$ sudo apt update
Hit:1 http://archive.ubuntu.com/ubuntu bionic InRelease
Get:2 http://archive.ubuntu.com/ubuntu bionic-updates InRelease [88.7 kB]
Ign:3 http://pkg.jenkins-ci.org/debian-stable binary/ InRelease
Get:4 http://pkg.jenkins-ci.org/debian-stable binary/ Release [2044 B]
Get:5 http://pkg.jenkins-ci.org/debian-stable binary/ Release.gpg [195 B]
Get:6 http://archive.ubuntu.com/ubuntu bionic-backports InRelease [74.6 kB]
Get:7 http://archive.ubuntu.com/ubuntu bionic/universe amd64 Packages [8570 kB]
Get:8 http://pkg.jenkins-ci.org/debian-stable binary/ Packages [17.6 kB]
Get:9 http://security.ubuntu.com/ubuntu bionic-security InRelease [88.7 kB]
Get:10 http://security.ubuntu.com/ubuntu bionic-security/main amd64 Packages [748 kB]
Get:11 http://security.ubuntu.com/ubuntu bionic-security/main Translation-en [237 kB]
Get:12 http://security.ubuntu.com/ubuntu bionic-security/restricted amd64 Packages [50.8 kB]
Get:13 http://security.ubuntu.com/ubuntu bionic-security/restricted Translation-en [12.3 kB]
Get:14 http://security.ubuntu.com/ubuntu bionic-security/universe amd64 Packages [673 kB]
Get:15 http://security.ubuntu.com/ubuntu bionic-security/universe Translation-en [223 kB]
Get:16 http://security.ubuntu.com/ubuntu bionic-security/multiverse amd64 Packages [7808 B]
Get:17 http://security.ubuntu.com/ubuntu bionic-security/multiverse Translation-en [2856 B]
Get:18 http://archive.ubuntu.com/ubuntu bionic/universe Translation-en [4941 kB]
Get:19 http://archive.ubuntu.com/ubuntu bionic/multiverse amd64 Packages [151 kB]
Get:20 http://archive.ubuntu.com/ubuntu bionic/multiverse Translation-en [108 kB]
Get:21 http://archive.ubuntu.com/ubuntu bionic-updates/main amd64 Packages [969 kB]
Get:22 http://archive.ubuntu.com/ubuntu bionic-updates/main Translation-en [329 kB]
Get:23 http://archive.ubuntu.com/ubuntu bionic-updates/restricted amd64 Packages [60.5 kB]
Get:24 http://archive.ubuntu.com/ubuntu bionic-updates/restricted Translation-en [14.7 kB]
Get:25 http://archive.ubuntu.com/ubuntu bionic-updates/universe amd64 Packages [1085 kB]
Get:26 http://archive.ubuntu.com/ubuntu bionic-updates/universe Translation-en [337 kB]
Get:27 http://archive.ubuntu.com/ubuntu bionic-updates/multiverse amd64 Packages [15.9 kB]
Get:28 http://archive.ubuntu.com/ubuntu bionic-updates/multiverse Translation-en [6420 B]
Get:29 http://archive.ubuntu.com/ubuntu bionic-backports/main amd64 Packages [7516 B]
Get:30 http://archive.ubuntu.com/ubuntu bionic-backports/main Translation-en [4764 B]
Get:31 http://archive.ubuntu.com/ubuntu bionic-backports/universe amd64 Packages [7484 B]
Get:32 http://archive.ubuntu.com/ubuntu bionic-backports/universe Translation-en [4436 B]
Fetched 18.8 MB in 58s (327 kB/s)
Reading package lists... Done
Building dependency tree
Reading state information... Done
102 packages can be upgraded. Run 'apt list --upgradable' to see them.
geekflare@ubuntu:~$

Step 5: Finally to install Jenkins, execute below command

<span style="font-weight: 400;">sudo apt install jenkins</span>

geekflare@ubuntu:~$ sudo apt install jenkins
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following additional packages will be installed:
  daemon
The following NEW packages will be installed:
  daemon jenkins
0 upgraded, 2 newly installed, 0 to remove and 102 not upgraded.
Need to get 65.7 MB of archives.
After this operation, 66.8 MB of additional disk space will be used.
Do you want to continue? [Y/n] Y
Get:1 http://archive.ubuntu.com/ubuntu bionic/universe amd64 daemon amd64 0.6.4-1build1 [99.5 kB]
Get:2 http://pkg.jenkins-ci.org/debian-stable binary/ jenkins 2.235.1 [65.6 MB]
Fetched 65.7 MB in 3min 34s (307 kB/s)
Selecting previously unselected package daemon.
(Reading database ... 29242 files and directories currently installed.)
Preparing to unpack .../daemon_0.6.4-1build1_amd64.deb ...
Unpacking daemon (0.6.4-1build1) ...
Selecting previously unselected package jenkins.
Preparing to unpack .../jenkins_2.235.1_all.deb ...
Unpacking jenkins (2.235.1) ...
Setting up daemon (0.6.4-1build1) ...
Setting up jenkins (2.235.1) ...
invoke-rc.d: could not determine current runlevel
Processing triggers for systemd (237-3ubuntu10.39) ...
Processing triggers for man-db (2.8.3-2ubuntu0.1) ...
Processing triggers for ureadahead (0.100.0-21) ...
geekflare@ubuntu:~$

Jenkins installed successfully. Now we can start Jenkins server.

Step 6: Starting Jenkins through systemctl command

<span style="font-weight: 400;">sudo systemctl start jenkins</span>

systemctl does not show the output so we can check the status through the below command. Through this command, we can check whether Jenkins is active or not.

<span style="font-weight: 400;">sudo systemctl status jenkins</span>

geekflare@ubuntu:~$ sudo systemctl status jenkins
● jenkins.service - LSB: Start Jenkins at boot time
   Loaded: loaded (/etc/init.d/jenkins; generated)
   Active: active (exited) since Sat 2020-04-04 10:10:19 UTC; 2 months 16 days ago
     Docs: man:systemd-sysv-generator(8)
    Tasks: 0 (limit: 4915)
   CGroup: /system.slice/jenkins.service

Apr 04 10:10:18 ip-172-31-17-25 systemd[1]: Starting LSB: Start Jenkins at boot time...
Apr 04 10:10:18 ip-172-31-17-25 jenkins[1984]: Correct java version found
Apr 04 10:10:18 ip-172-31-17-25 jenkins[1984]:  * Starting Jenkins Automation Server jenkins
Apr 04 10:10:18 ip-172-31-17-25 su[2037]: Successful su for root by root
Apr 04 10:10:18 ip-172-31-17-25 su[2037]: + ??? root:root
Apr 04 10:10:18 ip-172-31-17-25 su[2037]: pam_unix(su:session): session opened for user root by (uid=0)
Apr 04 10:10:18 ip-172-31-17-25 jenkins[1984]: mesg: ttyname failed: Inappropriate ioctl for device
Apr 04 10:10:18 ip-172-31-17-25 su[2037]: pam_unix(su:session): session closed for user root
Apr 04 10:10:19 ip-172-31-17-25 jenkins[1984]:    ...done.
Apr 04 10:10:19 ip-172-31-17-25 systemd[1]: Started LSB: Start Jenkins at boot time.
geekflare@ubuntu:~$

Step 6: Configuring port (Optional)

By default, Jenkins is run on 8080 port, and we need to make this port accessible from anywhere(if it is not accessible).

Let’s open the port :

<span style="font-weight: 400;">sudo ufw allow 8080</span>

We can check the status of the port below the following command:

<span style="font-weight: 400;">sudo ufw status</span>

geekflare@ubuntu:~$ sudo ufw status
Status: active
To           Action           From
--           ------           ----
8080         ALLOW            Anywhere
8080 (v6)    ALLOW            Anywhere (v6)
geekflare@ubuntu:~$

If the status showing of firewall inactive then run the following command otherwise it is not required

<span style="font-weight: 400;">sudo ufw allow OpenSSH</span>

followed by

<span style="font-weight: 400;">sudo ufw enable</span>

Jenkins Installation on CentOS

First, make sure JDK8+ is installed and running on the machine. If it is not installed execute below command to install OpenJDK 8 package.

sudo yum install java-1.8.0-openjdk-devel
[geekflare@localhost ~]$ sudo yum install java-1.8.0-openjdk-devel
CentOS-8 - AppStream                            1.0 kB/s | 4.3 kB     00:04
CentOS-8 - AppStream                            397 kB/s | 5.8 MB     00:14
CentOS-8 - Base                                 3.5 kB/s | 3.9 kB     00:01
CentOS-8 - Extras                               547  B/s | 1.5 kB     00:02
Jenkins-stable                                  6.5 kB/s | 2.9 kB     00:00
Dependencies resolved.
================================================================================
 Package                   Arch    Version                     Repository  Size
================================================================================
Installing:
 java-1.8.0-openjdk-devel  x86_64  1:1.8.0.252.b09-3.el8_2     AppStream  9.8 M

Transaction Summary
================================================================================
Install  1 Package

Total download size: 9.8 M
Installed size: 41 M
Is this ok [y/N]: y
Downloading Packages:
java-1.8.0-openjdk-devel-1.8.0.252.b09-3.el8_2. 531 kB/s | 9.8 MB     00:18
--------------------------------------------------------------------------------
Total                                           507 kB/s | 9.8 MB     00:19
Running transaction check
Transaction check succeeded.
Running transaction test
Transaction test succeeded.
Running transaction
  Preparing        :                                                        1/1
  Installing       : java-1.8.0-openjdk-devel-1:1.8.0.252.b09-3.el8_2.x86   1/1
  Running scriptlet: java-1.8.0-openjdk-devel-1:1.8.0.252.b09-3.el8_2.x86   1/1
  Verifying        : java-1.8.0-openjdk-devel-1:1.8.0.252.b09-3.el8_2.x86   1/1
Installed products updated.

Installed:
  java-1.8.0-openjdk-devel-1:1.8.0.252.b09-3.el8_2.x86_64

Complete!
[geekflare@localhost ~]$

To verify Java has been installed successfully, execute the below command

java -version
[geekflare@localhost ~]$ java -version
openjdk version "1.8.0_252"
OpenJDK Runtime Environment (build 1.8.0_252-b09)
OpenJDK 64-Bit Server VM (build 25.252-b09, mixed mode)
[geekflare@localhost ~]$

Once it is installed, then we are good to go for Jenkins installation.

Installation Steps

Step 1: First, Open Command Terminal

Step 2: To install Jenkins, First, we need to download and add Jenkins GPG key:

sudo wget -O /etc/yum.repos.d/jenkins.repo http://pkg.jenkins-ci.org/redhat-stable/jenkins.repo
[geekflare@localhost ~]$ sudo wget -O /etc/yum.repos.d/jenkins.repo http://pkg.jenkins-ci.org/redhat-stable/jenkins.repo
--2020-06-21 04:29:52--  http://pkg.jenkins-ci.org/redhat-stable/jenkins.repo
Resolving pkg.jenkins-ci.org (pkg.jenkins-ci.org)... 52.202.51.185, 64:ff9b::34ca:33b9
Connecting to pkg.jenkins-ci.org (pkg.jenkins-ci.org)|52.202.51.185|:80... connected.
HTTP request sent, awaiting response... 200 OK
Length: 85
Saving to: ‘/etc/yum.repos.d/jenkins.repo’

/etc/yum.repos.d/je 100%[==================>]      85  --.-KB/s    in 0s

2020-06-21 04:29:54 (2.61 MB/s) - ‘/etc/yum.repos.d/jenkins.repo’ saved [85/85]

[geekflare@localhost ~]$

Step 3: After downloading and adding Jenkins GPS key, next  Import Jenkins GPG Key:

sudo rpm --import https://jenkins-ci.org/redhat/jenkins-ci.org.key

Step 4: Update CentOS packages

sudo yum update
[geekflare@localhost ~]$ sudo yum update
Last metadata expiration check: 0:17:09 ago on Sun 21 Jun 2020 04:21:20 AM PDT.
Dependencies resolved.
Nothing to do.
Complete!
[geekflare@localhost ~]$

Step 5: After update centos packages, we are ready to install, Jenkins:

sudo yum install jenkins
[geekflare@localhost ~]$ sudo yum install jenkins
Last metadata expiration check: 0:19:26 ago on Sun 21 Jun 2020 04:21:20 AM PDT.
Dependencies resolved.
===============================================================================
 Package          Architecture    Version               Repository        Size
===============================================================================
Installing:
 jenkins          noarch          2.235.1-1.1           jenkins           63 M

Transaction Summary
===============================================================================
Install  1 Package

Total download size: 63 M
Installed size: 63 M
Is this ok [y/N]: y
Downloading Packages:
jenkins-2.235.1-1.1.noarch.rpm                 172 kB/s |  63 MB     06:16
-------------------------------------------------------------------------------
Total                                          172 kB/s |  63 MB     06:16
Running transaction check
Transaction check succeeded.
Running transaction test
Transaction test succeeded.
Running transaction
  Preparing        :                                                       1/1
  Running scriptlet: jenkins-2.235.1-1.1.noarch                            1/1
  Installing       : jenkins-2.235.1-1.1.noarch                            1/1
  Running scriptlet: jenkins-2.235.1-1.1.noarch                            1/1
  Verifying        : jenkins-2.235.1-1.1.noarch                            1/1
Installed products updated.

Installed:
  jenkins-2.235.1-1.1.noarch

Complete!
[geekflare@localhost ~]$

Step 6: Starting Jenkins through systemctl

sudo systemctl start jenkins

Since systemctl does not show the output so you can check the status through the below command. And through this command, you can check whether Jenkins is active or not.

sudo systemctl status jenkins
[geekflare@localhost ~]$ sudo systemctl status jenkins
[sudo] password for geekflare:
● jenkins.service - LSB: Jenkins Automation Server
   Loaded: loaded (/etc/rc.d/init.d/jenkins; generated)
   Active: active (running)
     Docs: man:systemd-sysv-generator(8)

Jun 20 11:15:22 localhost.localdomain systemd[1]: Starting LSB: Jenkins Automa>
Jun 20 11:15:23 localhost.localdomain runuser[1456]: pam_unix(runuser:session)>
Jun 20 11:15:33 localhost.localdomain jenkins[1433]: Starting Jenkins [  OK  ]
Jun 20 11:15:33 localhost.localdomain systemd[1]: Started LSB: Jenkins Automat>
Jun 21 04:23:04 localhost.localdomain systemd[1]: Stopping LSB: Jenkins Automa>
[geekflare@localhost ~]$

Step 7: Configuring the port(Optional)

By default, Jenkins is run on 8080 port, and we need to make this port accessible from anywhere(only if it is not accessible). Let’s open the port,

sudo firewall-cmd --permanent --zone=public --add-port=8080/tcp
[geekflare@localhost ~]$ sudo firewall-cmd --permanent --zone=public --add-port=8080/tcp
success
[geekflare@localhost ~]$

After configure port reload firewall the

sudo firewall-cmd --reload
[geekflare@localhost ~]$ sudo firewall-cmd --reload
success
[geekflare@localhost ~]$

Configuring Jenkins

Once Jenkins is installed, it will be running on port 8080,  Let’s configure it by navigating to http://localhost:8080 on our favorite browser.

Step-1: Visit http://localhost:8080

Step-2: To unlock the Jenkins, copy the administrator password from the file located at

  • For Windows

C:\Program Files (x86)\Jenkins\secrets\initialAdminPassword

/var/lib/jenkins/secrets/initialAdminPassword

Now, paste it in the Administrator password field. Then, click the Continue button.

Step-3: You can install either suggested plugins or you can select plugins depending on your use case. Here, we will install the suggested plugins.

Step-4: Please wait until all plugin is installed. When installation is done, click on Continue.

Step-5: Create an admin profile for Jenkins. Enter the required details and Click on Save and Continue.

Step-6: We can change the Jenkins URL if required, Let’s keep it default http://localhost:8080. Click Save and Finish to complete the configuration process. Now click on Start Using Jenkins

Finally, the configuration process is done, and the above one is the default, Welcome to Jenkins! page.

The Jenkins configuration step is similar for all OS, except Step 2 where we need to retrieve and enter the administrator password. This password could be retrieved from the file, store at the path shown on to Unlock Jenkins UI.

Conclusion

So the above were steps to install Jenkins on your favorite OS. Next, learn how to create your first Jenkins Pipelines.

Jenkins installation is easy and if you are setting up for the remote team then you can either get some Cloud VM and install it yourself or go for Jenkins hosting platform.

Thanks to our Sponsors
More great readings on Development
Power Your Business
Some of the tools and services to help your business grow.
  • Invicti uses the Proof-Based Scanning™ to automatically verify the identified vulnerabilities and generate actionable results within just hours.
    Try Invicti
  • Web scraping, residential proxy, proxy manager, web unlocker, search engine crawler, and all you need to collect web data.
    Try Brightdata
  • Semrush is an all-in-one digital marketing solution with more than 50 tools in SEO, social media, and content marketing.
    Try Semrush
  • Intruder is an online vulnerability scanner that finds cyber security weaknesses in your infrastructure, to avoid costly data breaches.
    Try Intruder
