How to Install IBM WebSphere and apply Fix Pack?

Untitled-1200-×-385-px-34
Invicti Web Application Security Scanner – the only solution that delivers automatic verification of vulnerabilities with Proof-Based Scanning™.

Procedure to install IBM WebSphere 8.5.5. Network Deployment and apply Fix Pack.

Pre-requisite

To install WebSphere ND, you must have product downloaded from IBM or some organization will have a custom package built by their engineering team. In either way – you should have the product package ready to get it installed.

To install WebSphere, you will also need IBM Installation Manager.

IBM Installation Manager is needed to install WebSphere. If you are working on WebSphere ND 7, then it’s something new for you, as it was not needed in prior to WebSphere 8 ND.

IM is also required to apply fix pack in WebSphere 8.5.5 version.

Component Version Supported Matrix

You will also need to check the supported matrix as listed below for Java SE, Java EE, Servlet, JSP, JSF, EJB, JMS, JDBC. Usually, a developer will confirm this.

  8.5.5 8.5 8.0 7.0 6.1
Java SE 6 & 7 6 & 7 6 6 5
Java EE 6 6 6 5 1.4
Servlet 3.0 3.0 3.0 2.5 2.4
JSP 2.2 2.2 2.2 2.1 2.0
JSF 2.0 2.0 2.0 1.2 1.1
EJB 3.1 3.1 3.1 3.0 3.0
JMS 1.1 1.1 1.1 1.1 1.1
JDBC 4.1 4.0 4.0 4.0 3.0

Downloading IBM Installation Manager

IBM IM can be downloaded from IBM website as explained here. Keep in mind you need to have IBM ID to download the IBM IM and WebSphere.

If you don’t have one, you can create one by registering yourself at

https://www.ibm.com/account/profile/us?page=reg

I assume you have IBM ID ready. Let’s start downloading IBM IM.

  • Open your favorite Internet browser
  • Download IBM IM 1.8.3 by clicking here
  • Select the one based on your platform. In this demonstration, I will proceed with Linux 64 bit.

1445251535_image1

  • Click on “Continue” and you will be given an option to either download using Download Director or using a browser (HTTPS).

1445251535_image2

  • Click on “Continue” to get the download link.

1445251535_image3

  • Click on the link to start downloading. It may take few minutes based on your Internet speed.
  • Once downloaded, you should have the following file
agent.installer.linux.gtk.x86_64_1.8.3000.20150606_0047.zip

Downloading WebSphere 8.5.5 ND

IBM offers 60 days trial for WebSphere ND Full profile, which I will use in this demonstration.

  • Open your favorite Internet browser
  • Access the following link
https://www.ibm.com/docs/en/samfess/8.2.1?topic=85-installing-websphere-application-server-version
  • You will see many products listed here, but following three is in our interest.

1445251535_image4

  • Click on “Download now” for all three parts. It may take few minutes based on your Internet speed.
  • Once downloaded, you should have following three files.
was.repo.8550.ndtrial_part3.zip
was.repo.8550.ndtrial_part2.zip
was.repo.8550.ndtrial_part1.zip

Installing IBM Installation Manager

  • Go to the path where you have downloaded the IBM IM Zip file
agent.installer.linux.gtk.x86_64_1.8.3000.20150606_0047.zip
  • unzip the file by using unzip command
unzip agent.installer.linux.gtk.x86_64_1.8.3000.20150606_0047.zip
  • Once extracted, you should see following

1445251535_image5

Let’s start the installation by executing install file

./install

It will start installation process in GUI mode, click on Next

1445251535_image6

  • Accept the license agreement and click Next

1445251535_image7

By default, it will install in /opt/IBM however, if you wish to change the directory, you can change it in this screen.

1445251535_image8

  • Review the installation summary information and click on Install to begin the installation.
  • If you wish to change anything (like a path), you can click on Back and do so.

1445251535_image9

It may take few seconds and give you confirmation on the package was installed.

1445251535_image10

You can close the window by clicking on a Close button.

Installing WAS 8.5.5 ND

Installation in GUI mode is easy and recommended for new WebSphere learner.

  • Go to the path where you have downloaded the following zip files.
was.repo.8550.ndtrial_part3.zip
was.repo.8550.ndtrial_part2.zip
was.repo.8550.ndtrial_part1.zip
  • Extract them by using unzip command
unzip was.repo.8550.ndtrial_part3.zip
unzip was.repo.8550.ndtrial_part3.zip
unzip was.repo.8550.ndtrial_part3.zip
  • Once extracted, you should have following

1445251535_image11

Let’s launch IBM Installation Manager to install the WebSphere ND.

Go to the path where you have installed IM. If you haven’t changed the path from default value then;

cd /opt/IBM/InstallationManager/eclipse/
  • Execute IBMIM to launch it
./IBMIM
  • You will get Installation Manager wizard likes below

1445251535_image12

  • Click on File >> Preferences
  • Click on Add Repository
  • Click on Browse to select the repository.config file. Repository.config file will be available on a path where you have extracted the downloaded WebSphere zip file.

1445251535_image13

  • Click Ok and Ok again.

You have successfully configured repository.config, which is necessary to begin the installation. Click on Install icon in the wizard.

1445251535_image14

  • Select the checkbox before version and click on Next

1445251535_image15

  • Accept the license agreement and click Next

1445251535_image16

  • Select the resource directory and click Next. You may leave it to the default path.

1445251535_image17

  • Select the path where WebSphere will be installed. If you are happy with installing under /opt/IBM/WebSphere then leave it to default path and click on Next

1445251535_image18

  • Select the language translation if needed, click on Next

1445251535_image19

  • You can choose the features to be installed in next screen. Most of the time you want to proceed with “Sample applications” as it helps administrator to deploy and test the environment. Click on Next

1445251535_image20



Finally, you will get review summary information. You can click on Back if anything to be changed else click on Install

1445251535_image21

It may take few minutes to install and once completed; you will have following confirmation.

1445251535_image22

  • Select None and click on Finish

Great, so now you are familiar with WebSphere Installation procedure.

Applying WebSphere Fix Pack

One of the essential tasks for WebSphere administrator is to ensure technology stack in a production environment is up-to-date. There are many including security, feature enhancements & bug fixes are released by IBM.

Downloading fix pack

Fix pack 6 is the latest pack available for WebSphere 8.5.5 which is shown in below demonstration.

  • Open your favorite Internet browser
  • Access the following link
http://www-01.ibm.com/support/docview.wss?uid=swg24040035
  • Select the zip file for your desired platform. I am using Linux so that I will proceed with the download for “Distributed” platform.

1445251535_image23

Fix Pack 6 is available in two parts, so you got to download both of them as shown below and click on Continue

1445251535_image24

  • Log in with your IBM ID to download the fix pack

1445251535_image25

  • Click on each file (part 1 & part 2) to download

1445251535_image26

  • Once downloaded, you should have the following file
8.5.5-WS-WAS-FP0000006-part1.zip
8.5.5-WS-WAS-FP0000006-part2.zip

Installing Fix Pack

Go to the path where you have downloaded the fix pack zip file

  • Extract them by using unzip command
unzip 8.5.5-WS-WAS-FP0000006-part1.zip
unzip 8.5.5-WS-WAS-FP0000006-part2.zip

Before you proceed to apply fix pack, you have to ensure WAS is not running. It would also be a good idea to take an entire WebSphere backup if you are doing in a critical environment.

  • Launch IBM Installation Manager
  • Click on File >> Preferences
  • Click on Add Repository
  • Click on Browse and select repository.config, which you got above after extracting fix pack
  • Click on OK

1445251535_image27

  • You should have something like below, click on OK to continue

1445251535_image28

  • Click Next

1445251535_image29

It will give you confirmation that Version 8.5.5.6 is recognized in a repository.config file. Click on Next

1445251535_image30

  • Accept the terms and click next

1445251535_image31

  • Here you can customize the features if you wish. Click on Next

1445251535_image29

  • Review the summary information and click on Update

1445251535_image32

It will take few minutes, and at the end, you will have success message as shown below.

1445251535_image33

This indicates you have applied Fix Pack 6 on 8.5.5 version and now WAS version is 8.5.5.6.

I hope this helps you to understand the IBM WebSphere installation procedure.
