Hoja de referencia del comando Docker para administradores de sistemas y desarrolladores ...
Docker es un sistema de contenedorización que empaqueta y ejecuta la aplicación con sus dependencias dentro de un contenedor. Hay varios comandos de Docker que debe conocer cuando trabaje con Docker. Este artículo trata sobre eso.
Si no sabe qué es Docker, puede tomar este Curso para principiantes de Udemy.
Finding the version
Una de las primeras cosas que desea saber es cómo encontrar la versión de Docker instalada.
geekflare@geekflare:/home/geekflare$ docker --version
Docker version 18.09.6, build 481bc77
Downloading image
Supongamos que necesita extraer la imagen de la ventana acoplable de Dockerhub (repositorio de Docker). El siguiente ejemplo de extracción de la imagen del servidor HTTP Apache.
geekflare@geekflare:/home/geekflare$ docker pull httpd
Using default tag: latest
latest: Pulling from library/httpd
f5d23c7fed46: Pull complete
b083c5fd185b: Pull complete
bf5100a89e78: Pull complete
98f47fcaa52f: Pull complete
622a9dd8cfed: Pull complete
Digest: sha256:8bd76c050761610773b484e411612a31f299dbf7273763103edbda82acd73642
Status: Downloaded newer image for httpd:latest
geekflare@geekflare:/home/geekflare$
Images
Enumere todas las imágenes de la ventana acoplable extraídas en el sistema con detalles de imagen como ETIQUETA / ID DE IMAGEN / TAMAÑO, etc.
geekflare@geekflare:/home/geekflare$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
httpd latest ee39f68eb241 2 days ago 154MB
hello-world latest fce289e99eb9 6 months ago 1.84kB
sequenceiq/hadoop-docker 2.7.0 789fa0a3b911 4 years ago 1.76GB
Run
Ejecute la imagen de la ventana acoplable mencionada en el comando. Este comando creará un contenedor acoplable en el que se ejecutará el servidor HTTP Apache.
geekflare@geekflare:/home/geekflare$ docker run -it -d httpd
09ca6feb6efc0578951a3e2557ed5855b2edda39a795d9703eb54d975930fe6e
What’s running?
ps
enumera todos los contenedores Docker que se están ejecutando con los detalles del contenedor.
geekflare@geekflare:/home/geekflare$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
09ca6feb6efc httpd "httpd-foreground" 36 seconds ago Up 33 seconds 80/tcp suspicious_bell
Como puede ver, el servidor Apache se está ejecutando en este contenedor acoplable.
ps -a
Enumere todos los contenedores de Docker que se ejecutan / salieron / detuvieron con los detalles del contenedor.
geekflare@geekflare:/home/geekflare$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
09ca6feb6efc httpd "httpd-foreground" 51 seconds ago Up 49 seconds 80/tcp suspicious_bell
2f6fb3381078 sequenceiq/hadoop-docker:2.7.0 "/etc/bootstrap.sh -d" 2 weeks ago Exited (137) 9 days ago quizzical_raman
9f397feb3a46 sequenceiq/hadoop-docker:2.7.0 "/etc/bootstrap.sh -…" 2 weeks ago Exited (255) 2 weeks ago 2122/tcp, 8030-8033/tcp, 8040/tcp, 8042/tcp, 8088/tcp, 19888/tcp, 49707/tcp, 50010/tcp, 50020/tcp, 50070/tcp, 50075/tcp, 50090/tcp determined_ritchie
9b6343d3b5a0 hello-world "/hello" 2 weeks ago Exited (0) 2 weeks ago peaceful_mclean
exec
Acceda al contenedor de la ventana acoplable y ejecutar comandos dentro del contenedor. Estoy accediendo al contenedor del servidor Apache en este ejemplo.
geekflare@geekflare:/home/geekflare$ docker exec -it 09ca6feb6efc bash
root@09ca6feb6efc:/usr/local/apache2# ls
bin build cgi-bin conf error htdocs icons include logs modules
root@09ca6feb6efc:/usr/local/apache2#
Tipo salida y presione enter para salir del contenedor.
Removing container
Elimine el contenedor de la ventana acoplable con el ID del contenedor mencionado en el comando.
geekflare@geekflare:/home/geekflare$ docker rm 9b6343d3b5a0
9b6343d3b5a0
Ejecute el siguiente comando para verificar si el contenedor se eliminó o no.
geekflare@geekflare:/home/geekflare$ docker ps -a CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES 09ca6feb6efc httpd "httpd-foreground" About a minute ago Up About a minute 80/tcp suspicious_bell 2f6fb3381078 sequenceiq/hadoop-docker:2.7.0 "/etc/bootstrap.sh -d" 2 weeks ago Exited (137) 9 days ago quizzical_raman 9f397feb3a46 sequenceiq/hadoop-docker:2.7.0 "/etc/bootstrap.sh -…" 2 weeks ago Exited (255) 2 weeks ago 2122/tcp, 8030-8033/tcp, 8040/tcp, 8042/tcp, 8088/tcp, 19888/tcp, 49707/tcp, 50010/tcp, 50020/tcp, 50070/tcp, 50075/tcp, 50090/tcp determined_ritchie
Removing image
Elimine la imagen de la ventana acoplable con la identificación de la imagen de la ventana acoplable mencionada en el comando
geekflare@geekflare:/home/geekflare$ docker rmi fce289e99eb9
Untagged: hello-world:latest
Untagged: hello-world@sha256:41a65640635299bab090f783209c1e3a3f11934cf7756b09cb2f1e02147c6ed8
Deleted: sha256:fce289e99eb9bca977dae136fbe2a82b6b7d4c372474c9235adc1741675f587e
Deleted: sha256:af0b15c8625bb1938f1d7b17081031f649fd14e6b233688eea3c5483994a66a3
geekflare@geekflare:/home/geekflare$
Restart Docker
Reinicie el contenedor de la ventana acoplable con la identificación del contenedor mencionada en el comando.
geekflare@geekflare:/home/geekflare$ docker restart 09ca6feb6efc
09ca6feb6efc
Ejecute el comando siguiente y verifique el parámetro STATUS para verificar si el contenedor se inició recientemente.
geekflare@geekflare:/home/geekflare$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
09ca6feb6efc httpd "httpd-foreground" 6 minutes ago Up 9 seconds 80/tcp suspicious_bell
Stopping Docker
Detenga un contenedor con el ID de contenedor mencionado en el comando.
geekflare@geekflare:/home/geekflare$ docker stop 09ca6feb6efc
09ca6feb6efc
Ejecute el siguiente comando para verificar si el contenedor aún se está ejecutando o se ha detenido.
geekflare@geekflare:/home/geekflare$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
Starting Docker
Este comando en la ventana acoplable inicia el contenedor de la ventana acoplable con la identificación del contenedor mencionada en el comando.
geekflare@geekflare:/home/geekflare$ docker start 09ca6feb6efc
09ca6feb6efc
Ejecute el siguiente comando para verificar si el contenedor se inició o no.
geekflare@geekflare:/home/geekflare$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
09ca6feb6efc httpd "httpd-foreground" 8 minutes ago Up 3 seconds 80/tcp suspicious_bell
Kill
Detenga el contenedor Docker inmediatamente. El comando de detención de Docker detiene el contenedor con gracia, esa es la diferencia entre los comandos de detención y de detención.
geekflare@geekflare:/home/geekflare$ docker kill 09ca6feb6efc
09ca6feb6efc
Ejecute el siguiente comando para ver si el contenedor se mató o no.
geekflare@geekflare:/home/geekflare$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
Commit
Guarde una nueva imagen de Docker con el ID de contenedor mencionado en el comando en el sistema local. En el siguiente ejemplo, geekflare es el nombre de usuario y httpd_image es el nombre de la imagen.
geekflare@geekflare:/home/geekflare$ docker commit 09ca6feb6efc geekflare/httpd_image
sha256:d1933506f4c1686ab1a1ec601b1a03a17b41decbc21d8acd893db090a09bb31c
Login
Inicie sesión en Docker Hub. Se le pedirán las credenciales de su Docker Hub para iniciar sesión.
geekflare@geekflare:/home/geekflare$ docker login
Login with your Docker ID to push and pull images from Docker Hub. If you don't have a Docker ID, head over to https://hub.docker.com to create one.
Username: geekflare
Password:
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store
Login Succeeded
Push
Cargue una imagen de la ventana acoplable con el nombre de la imagen que se menciona en el comando en la ventana acoplable.
geekflare@geekflare:/home/geekflare$ docker push geekflare/httpd_image
The push refers to repository [docker.io/geekflare/httpd_image]
734d9104a6a2: Pushed
635721fc6973: Mounted from library/httpd
bea448567d6c: Mounted from library/httpd
bfaa5f9c3b51: Mounted from library/httpd
9d542ac296cc: Mounted from library/httpd
d8a33133e477: Mounted from library/httpd
latest: digest: sha256:3904662761df9d76ef04ddfa5cfab764b85e3eedaf10071cfbe2bf77254679ac size: 1574
Docker network
El siguiente comando en Docker enumera los detalles de toda la red en el clúster.
geekflare@geekflare:/home/geekflare$ docker network ls
NETWORK ID NAME DRIVER SCOPE
85083e766f04 bridge bridge local
f51d1f3379e0 host host local
5e5d9a192c00 none null local
Hay varios otros comandos de red de Docker.
geekflare@geekflare:/home/geekflare$ docker network
Usage: docker network COMMAND
Manage networks
Commands:
connect Connect a container to a network
create Create a network
disconnect Disconnect a container from a network
inspect Display detailed information on one or more networks
ls List networks
prune Remove all unused networks
rm Remove one or more networks
Run 'docker network COMMAND --help' for more information on a command.
Docker info
Obtenga información detallada sobre la ventana acoplable instalada en el sistema, incluida la versión del kernel, el número de contenedores e imágenes, etc.
geekflare@geekflare:/home/geekflare$ docker info
Containers: 3
Running: 1
Paused: 0
Stopped: 2
Images: 3
Server Version: 18.09.6
Storage Driver: overlay2
Backing Filesystem: extfs
Supports d_type: true
Native Overlay Diff: true
Logging Driver: json-file
Cgroup Driver: cgroupfs
Plugins:
Volume: local
Network: bridge host macvlan null overlay
Log: awslogs fluentd gcplogs gelf journald json-file local logentries splunk syslog
Swarm: inactive
Runtimes: runc
Default Runtime: runc
Init Binary: docker-init
containerd version: bb71b10fd8f58240ca47fbb579b9d1028eea7c84
runc version: 2b18fe1d885ee5083ef9f0838fee39b62d653e30
init version: fec3683
Security Options:
apparmor
seccomp
Profile: default
Kernel Version: 4.18.0-25-generic
Operating System: Ubuntu 18.10
OSType: linux
Architecture: x86_64
CPUs: 1
Total Memory: 4.982GiB
Name: geekflare
ID: RBCP:YGAP:QG6H:B6XH:JCT2:DTI5:AYJA:M44Z:ETRP:6TO6:OPAY:KLNJ
Docker Root Dir: /var/lib/docker
Debug Mode (client): false
Debug Mode (server): false
Username: geekflare
Registry: https://index.docker.io/v1/
Labels:
Experimental: false
Insecure Registries:
127.0.0.0/8
Live Restore Enabled: false
Product License: Community Engine
Copying file
Copie un archivo de un contenedor de la ventana acoplable al sistema local.
En este ejemplo, estoy copiando el archivo httpd.pid dentro de un contenedor docker con la identificación 09ca6feb6efc a / home / geekflare /
geekflare@geekflare:/home/geekflare$ sudo docker cp 09ca6feb6efc:/usr/local/apache2/logs/httpd.pid /home/geekflare/
[sudo] password for geekflare:
Ejecute el siguiente comando para verificar si el archivo se copió o no.
geekflare@geekflare:/home/geekflare$ ls
Desktop Documents example examples.desktop httpd.pid nginx_new.yml nginx.yml
Checking history
Muestra el historial de una imagen de la ventana acoplable con el nombre de la imagen mencionado en el comando.
geekflare@geekflare:/home/geekflare$ docker history httpd
IMAGE CREATED CREATED BY SIZE COMMENT
ee39f68eb241 2 days ago /bin/sh -c #(nop) CMD ["httpd-foreground"] 0B
<missing> 2 days ago /bin/sh -c #(nop) EXPOSE 80 0B
<missing> 2 days ago /bin/sh -c #(nop) COPY file:c432ff61c4993ecd… 138B
<missing> 4 days ago /bin/sh -c set -eux; savedAptMark="$(apt-m… 49.1MB
<missing> 4 days ago /bin/sh -c #(nop) ENV HTTPD_PATCHES= 0B
<missing> 4 days ago /bin/sh -c #(nop) ENV HTTPD_SHA256=b4ca9d05… 0B
<missing> 4 days ago /bin/sh -c #(nop) ENV HTTPD_VERSION=2.4.39 0B
<missing> 4 days ago /bin/sh -c set -eux; apt-get update; apt-g… 35.4MB
<missing> 4 days ago /bin/sh -c #(nop) WORKDIR /usr/local/apache2 0B
<missing> 4 days ago /bin/sh -c mkdir -p "$HTTPD_PREFIX" && chow… 0B
<missing> 4 days ago /bin/sh -c #(nop) ENV PATH=/usr/local/apach… 0B
<missing> 4 days ago /bin/sh -c #(nop) ENV HTTPD_PREFIX=/usr/loc… 0B
<missing> 5 days ago /bin/sh -c #(nop) CMD ["bash"] 0B
<missing> 5 days ago /bin/sh -c #(nop) ADD file:71ac26257198ecf6a… 69.2MB
Checking logs
Muestre los registros del contenedor de la ventana acoplable con la identificación contenida mencionada en el comando.
geekflare@geekflare:/home/geekflare$ docker logs 09ca6feb6efc
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
[Mon Jul 15 14:01:55.400472 2019] [mpm_event:notice] [pid 1:tid 140299791516800] AH00489: Apache/2.4.39 (Unix) configured -- resuming normal operations
[Mon Jul 15 14:01:55.400615 2019] [core:notice] [pid 1:tid 140299791516800] AH00094: Command line: 'httpd -D FOREGROUND'
[Mon Jul 15 14:08:36.798229 2019] [mpm_event:notice] [pid 1:tid 140299791516800] AH00491: caught SIGTERM, shutting down
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
[Mon Jul 15 14:08:38.259870 2019] [mpm_event:notice] [pid 1:tid 139974087980160] AH00489: Apache/2.4.39 (Unix) configured -- resuming normal operations
[Mon Jul 15 14:08:38.260007 2019] [core:notice] [pid 1:tid 139974087980160] AH00094: Command line: 'httpd -D FOREGROUND'
[Mon Jul 15 14:09:01.540647 2019] [mpm_event:notice] [pid 1:tid 139974087980160] AH00491: caught SIGTERM, shutting down
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
[Mon Jul 15 14:10:43.782606 2019] [mpm_event:notice] [pid 1:tid 140281554879616] AH00489: Apache/2.4.39 (Unix) configured -- resuming normal operations
[Mon Jul 15 14:10:43.782737 2019] [core:notice] [pid 1:tid 140281554879616] AH00094: Command line: 'httpd -D FOREGROUND'
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
[Mon Jul 15 14:14:08.270906 2019] [mpm_event:notice] [pid 1:tid 140595254346880] AH00489: Apache/2.4.39 (Unix) configured -- resuming normal operations
[Mon Jul 15 14:14:08.272628 2019] [core:notice] [pid 1:tid 140595254346880] AH00094: Command line: 'httpd -D FOREGROUND'
Searching image
Busque una imagen de docker en dockerhub con el nombre mencionado en el comando.
geekflare@geekflare:/home/geekflare$ docker search hadoop
NAME DESCRIPTION STARS OFFICIAL AUTOMATED
sequenceiq/hadoop-docker An easy way to try Hadoop 611 [OK]
uhopper/hadoop Base Hadoop image with dynamic configuration… 98 [OK]
harisekhon/hadoop Apache Hadoop (HDFS + Yarn, tags 2.2 - 2.8) 54 [OK]
bde2020/hadoop-namenode Hadoop namenode of a hadoop cluster 22 [OK]
kiwenlau/hadoop Run Hadoop Cluster in Docker Containers 19
izone/hadoop Hadoop 2.8.5 Ecosystem fully distributed, Ju… 14 [OK]
uhopper/hadoop-namenode Hadoop namenode 9 [OK]
bde2020/hadoop-datanode Hadoop datanode of a hadoop cluster 9 [OK]
singularities/hadoop Apache Hadoop 8 [OK]
uhopper/hadoop-datanode Hadoop datanode 7 [OK]
harisekhon/hadoop-dev Apache Hadoop (HDFS + Yarn) + Dev Tools + Gi… 6 [OK]
Updating configuration
Actualice las configuraciones de contenedores. Esto muestra todas las opciones de actualización.
geekflare@geekflare:/home/geekflare$ docker update --help
Usage: docker update [OPTIONS] CONTAINER [CONTAINER...]
Update configuration of one or more containers
Options:
--blkio-weight uint16 Block IO (relative weight), between 10 and 1000, or 0 to disable
(default 0)
--cpu-period int Limit CPU CFS (Completely Fair Scheduler) period
--cpu-quota int Limit CPU CFS (Completely Fair Scheduler) quota
--cpu-rt-period int Limit the CPU real-time period in microseconds
--cpu-rt-runtime int Limit the CPU real-time runtime in microseconds
-c, --cpu-shares int CPU shares (relative weight)
--cpus decimal Number of CPUs
--cpuset-cpus string CPUs in which to allow execution (0-3, 0,1)
--cpuset-mems string MEMs in which to allow execution (0-3, 0,1)
--kernel-memory bytes Kernel memory limit
-m, --memory bytes Memory limit
--memory-reservation bytes Memory soft limit
--memory-swap bytes Swap limit equal to memory plus swap: '-1' to enable unlimited swap
--restart string Restart policy to apply when a container exits
Ejecute el siguiente comando para actualizar la configuración de la CPU del contenedor de la ventana acoplable con la identificación del contenedor mencionada en el comando.
geekflare@geekflare:/home/geekflare$ docker update -c 1 2f6fb3381078
2f6fb3381078
Creating volume
Cree un volumen que el contenedor de la ventana acoplable utilizará para almacenar datos.
geekflare@geekflare:/home/geekflare$ docker volume create
7e7bc886f69bb24dbdbf19402e31102a25db91bb29c56cca3ea8b0c611fd9ad0
Ejecute el siguiente comando si el volumen se creó o no.
geekflare@geekflare:/home/geekflare$ docker volume ls
DRIVER VOLUME NAME
local 7e7bc886f69bb24dbdbf19402e31102a25db91bb29c56cca3ea8b0c611fd9ad0
Installing plugin
Instale un complemento de docker vieux / sshfs con el entorno de depuración establecido en 1.
geekflare@geekflare:/home/geekflare$ docker plugin install vieux/sshfs DEBUG=1
Plugin "vieux/sshfs" is requesting the following privileges:
- network: [host]
- mount: [/var/lib/docker/plugins/]
- mount: []
- device: [/dev/fuse]
- capabilities: [CAP_SYS_ADMIN]
Do you grant the above permissions? [y/N] y
latest: Pulling from vieux/sshfs
52d435ada6a4: Download complete
Digest: sha256:1d3c3e42c12138da5ef7873b97f7f32cf99fb6edde75fa4f0bcf9ed277855811
Status: Downloaded newer image for vieux/sshfs:latest
Installed plugin vieux/sshfs
Run the below command to list the docker plugins.
geekflare@geekflare:/home/geekflare$ docker plugin ls
ID NAME DESCRIPTION ENABLED
2a32d1fb95af vieux/sshfs:latest sshFS plugin for Docker true
Logout
Cerrar sesión en dockerhub.
geekflare@geekflare:/home/geekflare$ docker logout
Removing login credentials for https://index.docker.io/v1/
En resumen
Espero que ya hayas comprendido bien los comandos de la ventana acoplable. Pruebe esos comandos en su entorno de desarrollo o laboratorio para practicar y aprender.
Si está interesado en aprender Docker y Kubernetes, consulte este curso en línea.
