  •  JMX (Java Management Extension) is a very powerful technology, which lets you administer, monitor and configure Tomcat MBeans.

    If you are a Tomcat administrator, then you should be familiar with how to enable JMX in tomcat to monitor Heap Memory, Threads, CPU Usage, Classes, and configure various MBeans.

    In this article, I will talk about how to enable and connect to Tomcat with JConsole.

    I assume you have Tomcat installed if not; you can refer installation guide.

    • Go to path where you have Tomcat installed
    • Go to bin folder
    • Create a file as “setenv.sh”
    • Modify file using vi editor and add following
    CATALINA_OPTS="-Dcom.sun.management.jmxremote -Dcom.sun.management.jmxremote.port=9000 -Dcom.sun.management.jmxremote.ssl=false -Dcom.sun.management.jmxremote.authenticate=false"
    • Save the file with “:w
    • Change the file permission as executable
    chmod 755 setenv.sh

    Before you start Tomcat to verify JMX, let’s take a look at the above configuration.

    1. Dcom.sun.management.jmxremote.port=9000 – you can modify the port number if you want.
    2. Dcom.sun.management.jmxremote.ssl=false – this means connect without SSL
    3. Dcom.sun.management.jmxremote.authenticate=false – this means no authentication needed when you use JMX client to connect to Tomcat instance.

    Let’s start the tomcat by startup.sh script file. Once started, you can verify either using netstat or ps –ef grep command.

    To verify using netstat

    netstat –anlp | grep 9000

    [[email protected] ~]# netstat -anlp |grep 9000
    tcp6       0     0 :::9000                 :::*                   LISTEN     9372/java
    [[email protected] ~]#

    To verify using ps command

    ps –ef |grep jmx

    [[email protected] ~]# ps -ef|grep jmx
    root       9372     1 0 21:30 pts/0   00:00:04 java -Djava.util.logging.config.file=/home/chandan/Downloads/apache-tomcat-8.0.28/conf/logging.properties -Djava.util.logging.manager=org.apache.juli.ClassLoaderLogManager -Dcom.sun.management.jmxremote -Dcom.sun.management.jmxremote.port=9000 -Dcom.sun.management.jmxremote.ssl=false -Dcom.sun.management.jmxremote.authenticate=false -Djava.endorsed.dirs=/home/chandan/Downloads/apache-tomcat-8.0.28/endorsed -classpath /home/chandan/Downloads/apache-tomcat-8.0.28/bin/bootstrap.jar:/home/chandan/Downloads/apache-tomcat-8.0.28/bin/tomcat-juli.jar -Dcatalina.base=/home/chandan/Downloads/apache-tomcat-8.0.28 -Dcatalina.home=/home/chandan/Downloads/apache-tomcat-8.0.28 -Djava.io.tmpdir=/home/chandan/Downloads/apache-tomcat-8.0.28/temp org.apache.catalina.startup.Bootstrap start
    root       9816   9781 0 21:46 pts/0   00:00:00 grep --color=auto jmx
    [[email protected] ~]#

    This concludes jmx is enabled in Tomcat and it’s time to connect using JMX client.

    You may use any client, however, to show you I will use jconsole, which comes with java.

    Connect Tomcat JMX using Jconsole

    • Go to the path where you have jconsole

    Tip: you may use the find command to search if you are not sure.

    • Execute jconsole

    This will popup Java Monitoring & Management Console.

    • Select “Remote Process”
    • Enter the server host and port details


    • Click on “Connect”

    This will connect to Tomcat and show you very nice graphs of CPU, Memory & Thread usage. This becomes very handy during troubleshooting.


    You may also perform GC from the console.

    • Click on Memory tab, and you will see “Perform GC” button


    As mentioned at the beginning of the article, you may also configure MBeans for the classes.

    This is often used if you have to change the logging or specific parameters at runtime.

    So go ahead and play around with Jconsole and JMX. It’s a wonderful tool for troubleshooting and monitoring.
